Introduction
Thank you for purchasing an Evolution ® radial engine, one of the finest engines in the market-
place today. Evolution is committed to you having a positive experience and a lifetime of great
operation with your new engine.
It is important that you read the engine manual before starting the engine for the first time.
Evolution radial engines have different requirements than engines that you may have operated
in the past. The manual provides important information for installing the engine, selecting the
correct propeller and proper engine break-in procedures.
Engine Specifications
EVOE 735 EVOE 777 EVOE 999
cylinders 7 7 9
capacity 2.1 cu in (34.9cc) 4.7 cu in (77cc) 6.0 cu in (99cc)
capacity per cylinder 0.3 cu in (5.0cc) 0.66 cu in (11cc) 0.66 cu in (11cc)
bore 0.71 in (18mm) 0.93 in (23.7mm) 0.93 in (23.7mm)
stroke 0.79 in (20mm) 0.98 in (25mm) 0.98 in (25mm)
power 2.2 hp 4.8 hp 6.0 hp
crankshaft thread size 8 x 1mm 10 x 1mm 10 x 1mm
RPM range 1000–6300 1000–6000 1000–6000
maximum RPM 6700 6300 6300
engine diameter 7.3 in (185mm) 9.1 in (23 cm) 10.2 in (26 cm)
engine length 6.3 in (159mm) 7.9 in (20 cm) 7.9 in (20 cm)
weight 3.1 lb (1.4 kg) 5.7 lb (2.6 kg) 7.7 lb (3.5 kg)
fuel usage (approx.) 1.0 oz (28 ml)/min 2.2 oz (62 ml)/min 2.8 oz (80 ml)/min
propellers 2-Blade
17 x 8, 17 x 10,
17 x 12, 18 x 8
2-Blade
22 x 12, 24 x 10
3-Blade
22 x 10
2-Blade
26 x 10, 24 x 12
Needed to Complete
• Propeller • Engine baffles
• Fuel line (3mm or 3.5mm ID) • On-board glow driver (optional)
• Engine mounting screws • Glow driver battery
(1.2V 6000–9000mAh Ni-MH battery required)
Installing the Engine in the Airframe
Properly installing the engine to either the airframe or an engine test stand for break-in is crucial
to getting the most power and longest life from your engine.
WARNING: Always attach the engine mounting ring to a flat plate surface, such as
6–8mm plywood or carbon fiber plate.
WARNING: Never use a standoff between the firewall and the mounting ring. Vibration
between the standoff and the mounting ring will damage the mounting ring and cause
the engine to separate from the airframe.
