Supporting Equipment
Contact ETS-Lindgren for sizes and sensitivities of other current
probes.
When using the Model 95242-1 to perform susceptibility tests, the following
equipment may be required.
O PTIONAL I NJECTION P ROBE
The Model 93686-1 Current Probe with a 6.6 cm window diameter may be used
as a bulk current injection probe over the frequency range 50 kHz to 2 MHz.
M ODEL 95241-1 C ALIBRATION J IG
The Model 95241-1 Calibration Jig is used in equipment setup for measuring
insertion loss of the current probe and is essential to set up equipment for some
susceptibility test procedures.
C URRENT M ONITORING PROBES
Suggested current monitoring probes are Model 91550-1 (10 kHz to 100 MHz)
and Model 94111-1 (1 MHz to 1 GHz). These probes have a 1.25-inch (3.2-cm)
window size and a transfer impedance of 1 ohm to 6 ohms over the 50 kHz to
400 MHz frequency range.
