Test Setup Equipment

The following equipment may be needed to set up the test environment.

• Current Injection Probes:

95236-1

95242-1

• Calibration Jig 95241-1

• Current Monitoring Probes

• Signal

Source/Generator

• Power Amplifier(s):

The power amplifier should be capable of

supplying the full rated power into the current

injection probes (which have a high VSWR)

with a low harmonic content.

• Spectrum Analyzer or Measuring Receivers

• Directional

Coupler

• RF

Voltmeter(s)

• RF Absorbing Clamp

• RF

Attenuator

• RF

Loads

18 |
