5.0 Conducted Emission: Transfer Impedance

The Bulk Current Injection Probe (BCIP) may also be used as a sensor for

measuring conducted emission. The RF current

I

P

(in microamperes) in the

conductor under test is determined from the measuring receiver reading of the

probe output

E

S

(in microvolts) divided by the probe transfer impedance

Z

T

(in ohms).

I

P

= E

S

/ Z

T

Or, in dB:

I

P

(dBµA) = E

S

(dBµV) – Z

T

(dB)

The transfer impedance is determined by passing a known RF current

I

P

through

the primary test conductor and noting the voltage

E

S

developed across a 50 ohm

load on the probe output.

Z

T

= E

S

/ I

P

Calibration gig 95241-1 may be used for this determination. Following are the

typical transfer impedance values when the BCIP is used as a sensor.

High sensitivity and minimal core gap indicate that the current probe

should be used only on signal lines where heavy currents are not

encountered. Heavy currents may affect measurement accuracy

should current probe core saturation occur.

Conducted Emission: Transfer Impedance

|

21
