Insertion Loss

Procedure

1.

Connect the signal generator output directly to the RF voltmeter input

as show in Typical Reference Calibration Setup on page 25, indicated

by the dashed line. Use the same cables which connected the

calibration jig and the injection probe under test. Tune to the test

frequency and adjust the signal level for a reference of 0 dBm

indication on the RF voltmeter.

2.

Without changing control settings, connect the signal generator output

to the bulk current injection probe input and connect the calibration jig

connector to the RF voltmeter input.

3.

Note the RF voltmeter output in dB. The difference between this

reading and 0 dB is the insertion loss. In this measurement, the loss

cannot be less than 3 dB since half the injected power is absorbed by

the 50 ohm termination that is particularly loading (50%) the

calibration jig.
