background image

Electrical Specifications

95236-1

95242-1

Frequency Range:

1 MHz–100 MHz

10 MHz–400 MHz

Maximum Input
Power:

100 W

*

200

W

**

Maximum Input
Current:

20 Amperes

60 Amperes

Maximum Core
Temperature:

80

°

C 80

°

C

Recommended
Maximum
Temperature Rise:

35

°

C 35

°

C

Maximum Time for
Continuous Rating at
Full Power:

30 minutes

30 minutes

Turns Ratio:

1:2 1:1

Inductance:

47

μH, ±20%

0.8

μH, ±20%

*

95236-1: The power limit of the 95236-1 is 100 W. Powers in excess of

75 W should be used with care to avoid excessive temperature in the

equipment under test. Prolonged testing should be avoided, particularly if

unattended.

**

95242-1: The power limit of the 95242-1 is 200 W. Powers in excess of

100 W should be used with care to avoid excessive temperature in the

equipment under test. Prolonged testing should be avoided, particularly if

unattended.

14 |

Specifications
