1.0 Introduction

The

ETS-Lindgren Bulk Current Injection Probe (BCIP) Series is used to

inject RF current into conductors and cables of electrical and electronic

equipment undergoing susceptibility testing. This manual includes information for

these BCIP models:

• Model

95236-1

• Model

95242-1

The BCIP provides a means of applying a controlled RF stress level to an

instrument under test through interconnecting cables or power cables without

requiring a direct connection to the conductor(s) of interest. The models in this

series are simply clamped around the test conductor which then becomes a

one turn secondary winding, with the current probe forming the core and primary

winding of an RF transformer. RF energy can be injected onto single and

multi-conductor cables, grounding and bonding straps, outer conductors of

shielding conduits and coaxial cables, and so on.

Because of the high efficiency design, the probes can also be used as sensors.

Frequency Range

*

Useful Range

95236-1

1 MHz–100 MHz

10 kHz–100 MHz

95242-1

10 MHz–400 MHz

2 MHz–400 MHz

*

The BCIP Series is especially designed to provide minimum insertion loss

over these frequency ranges.

Introduction

|

7
