Standard head anchorage standard sill anchorage – EFCO S5500 SSG User Manual
Page 19
EFCO CORPORATION 6/2012
PART NO. Y554
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions
Section III: Typical Anchorage Methods
STANDARD HEAD ANCHORAGE
STANDARD SILL ANCHORAGE
Apply dead load
shims at anchors and
below verticals.
ANCHOR BOLTS
WITH SLEEVES
AS REQ’D.
ANCHOR BOLTS
AS REQ’D.
