Coral Industries Provincial Prestige Bypass with Towel Bars and SSL Sill - 2PG6 - Manual (Page 6)

2PG6-GP 3/06
Inside
Door
Panel
Header
Guide
Water
Deflector
P
Jamb
INSIDE OF BATH
C
Header
C
O
Inside
Door
Panel
Tub
Outside
Door
Panel
Door
Silencer
Door
Silencer
Outside
Door
Panel
Inside
Door
Panel
E
Sill
Guide
O
E
Sill A
Sill
A
B
OUTSIDE
OF BATH
OUTSIDE
OF BATH
OUTSIDE
OF BATH
Lift inside door panel into header with towel
bar facing inside of bath. Seat rollers on
roller track while guiding bottom of door into
sill guide.
7 Hanging Door Panel
Snap door silencer (E) into bottom of
outside door panel.
Lift outside door into header with towel bar
facing outside of bath. Position bottom
channel of door over front high ridge of sill
as rollers are seated in header.
8 Door Silencer
(E)
Place water deflector (P) in position
between high ridge of sill and side of jamb.
Repeat for opposite side.
9 Water Deflector
(P)
The use of a caulking compound will assure a
water-tight seal. Seal unit by applying caulk along
outside edge of enclosure where metal and bath
meet, especially where sill meets tub.
If desired, caulk inside of enclosure where jambs
meet walls.
Caulk outside
of enclosure
where metal
and shower
meet.
If desired,
caulk inside of
shower where
jambs and walls
meet.
10 Caulking
OUTSIDE OF SHOWER
A
