2PG6-GP 3/06
Before starting installation of your new enclosure, carefully read all instructions
and lay out parts to become familiar with their identity.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surrounds with board reinforced mounting areas. Mounting holes in this case should be drilled
with an 1/8" drill bit.
Mounting of this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes
in the tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors
into the holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
The use of a caulking compound can assure a water-tight seal when applied along outside edge of the enclosure where metal
and bath meet. If desired, caulk inside of enclosure where jambs meet walls.
C leaning and care of your enclosure is important to its lasting beauty. We suggest using a nonabrasive liquid cleaner.
Never use scouring powder or pads.
Do not try to cut the mirrors or glass used in this enclosure.
Tempered glass and mirrors will disintegrate if cut.
PARTS LIST
TOOLS
NEEDED
1/8" Drill Bit
3/16" Drill Bit
Pencil
Measuring Tape
Hacksaw
Phillips Screw Driver
Silicone Caulk
File
Drill
Level
Masking Tape
Allen Wrench
(3/16" Masonry Bit for
Ceramic Tile)
DESCRIPTION KEY PART
FRAME PACKAGE
HARDWARE BAG
QTY
A SILL A610 1
B JAMB A605 2
C HEADER A631 1
E DOOR SILENCER HT33 1
F ANCHOR H002 6
G BUMPER H100 2
H ROLLER H342 4
M 8-32 X 3/8 TRUSS HEAD SCREW H430 4
I 8A X 3/8 TRUSS HEAD SCREW H470 2
J 8A X 1 1/4 PAN HEAD SCREW H480 6
K TOWEL BAR KIT HT24
TOWEL BAR HT24 2
ROUND BUSHING 4
PLASTIC WASHER 8
END CAP / SCREW 4
N 8B X 3/8 FLAT HEAD SCREW H468 2
O GUIDE HG80 1
P WATER DEFLECTOR HA10 2
