5
Step 11 Twist the wires of the WingMan's cable and feed the WingMan's cable through the cable hole and into the trunk (see Figures 13
and 14).
FIGURE 12
Step 8 Position the mounting brackets so that they are 12"across between the centers of the mounting holes and the passenger side
bracket is firmly against the slight hump in the rear deck's fabric (see Figure 10).
Step 9 Tighten the mounting bracket nuts from inside the trunk of the Crown Vic (as shown in Figure 11).
Note: Only tighten the brackets tight enough to draw them down into the fabric of the rear deck but not so tight that the
brackets cannot be turned slightly as needed to center the WingMan Bar in the rear window and align the mounting bolts.
FIGURE 10 FIGURE 11
Step 10 Remove the two outer child restraint seat belt covers (see Figure 12). Note: The seat belt covers may be kept in place if
desired. The interfering portion of the covers must be trimmed to fit after the WingMan Rear Bar is installed.
FIGURE 13 FIGURE 14
