Installation examples – Code 3 Universal Mirror User Manual
Page 7
7
Installation Examples:
FORD EXPLORER
CHEVROLET TAHOE
FORD EXPEDITION
(Extended depth mounting bracket used on
vehicles with a greater slope than 32 deg.
off of vertical or 58 degrees horizontal)
(Common pivot bracket is used in all
installations)
Extended mounting
bracket assembly
(Using T56499
Bracket)
CHEVROLET IMPALA
CHEVROLET CAPRICE- (SHOWN ON
FRONT COVER OF MANUAL)
FORD CROWN VIC- (SHOWN ON
PAGE 5 IN MANUAL)
DODGE CHARGER
