Introduction
The controller features eight independent outputs and four operating modes (Left , Center-out, Right , Flash) and is specifically
designed to operate a stand-alone TriCore® Narrowstik™, LED Narrowstik™, internal lightbar LED Narrowstik™ or Large LED Nar-
rowstik™ as well as LC-Stick versions. The controller features a fast override mode, auxiliary device control, external flash enable,
backlighting and a low-intensity ( DIM ) mode. The low-intensity (DIM) Mode has been designed to work with the new TriCore Nar-
rowStik and with all older NarrowStik models. In addition, the controller has a programming input that gives the end user the ability
to program each slide switch position from a group of available traffic directing signals in the Left, Center and Right positions as well
as traffic warning patterns in the Flash position (see “Programming” on page 8).
Note: This controller is designed to operate
stand-alone LED NarrowStik products. This control head is NOT designed to operate halogen or incandescent
ArrowStik products. Attempting to operate the products with this controller could damage the controller outputs.
The use of this or any warning device does not ensure that all drivers can or will observe or react to an
emergency warning signal. Never take the right-of-way for granted. It is your responsibility to be sure
you can proceed safely before entering an intersection, driving against traffic, responding at a high rate of
speed, or walking on or around traffic lanes.
The effectiveness of this warning device is highly dependent upon correct mounting and wiring. Read and
follow the manufacturer’s instructions before installing or using this device. The vehicle operator should
insure daily that all features of the device operate correctly. In use, the vehicle operator should insure the
projection of the warning signal is not blocked by vehicle components (i.e.: open trunks or compartment
doors), people, vehicles, or other obstructions.
This equipment is intended for use by authorized personnel only. It is the user’s responsibility to
understand and obey all laws regarding emergency warning devices. The user should check all
applicable city, state and federal laws and regulations.
Code 3, Inc., assumes no liability for any loss resulting from the use of this warning device.
Proper installation is vital to the performance of this warning device and the safe operation of the
emergency vehicle. It is important to recognize that the operator of the emergency vehicle is under
psychological and physiological stress caused by the emergency situation. The warning device should
be installed in such a manner as to: A) Not reduce the output performance of the system, B) Place the
controls within convenient reach of the operator so that he can operate the system without losing eye
contact with the roadway.
Emergency warning devices often require high electrical voltages and/or currents. Properly protect and
use caution around live electrical connections. Grounding or shorting of electrical connections can cause
high current arcing, which can cause personal injury and/or severe vehicle damage, including fire.
PROPER INSTALLATION COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF
EMERGENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF EMERGENCY
PERSONNEL AND THE PUBLIC.
wARNING!
Unpacking & Pre-installation
After unpacking the items, carefully inspect the unit and its associated parts for any damage that may have been caused
in transit. Report any damage to the carrier immediately.
Installation & Mounting
The product is shipped fully assembled and ready to be installed. Mounting fasteners and brackets have been enclosed in
the parts bag. If problems arise during installation, questions can be directed to the Technical Hotline number given on the
last page of this manual. This control head is intended to control one Code 3® Narrowstik™.
Control Head Operating Specifications
Electrical
Operating Temperature Range: -40 C to + 85 C (-40 F to +185 F)
Operating Voltage Range: 10 to 16 Vdc. Power input has reverse voltage and transient protection.
Operating Current Requirements:
250mA max
Control Output Current Rating: Switch 3 Amps max per output, 50% duty cycle. Connect to LED Narrowstik® modules
only.
