6
Maintenance
Dual Filament Lamp Assembly Replacement
1.
Turn off power to the power source and allow the lamp assembly to cool for 10 minutes.
2.
Remove the lens by unscrewing the four mounting screws.
3.
Carefully grab the base of the lamp assembly and twist counterclockwise 1/8 turn. Pull straight out.
4.
Disconnect the lamp assembly from the cable.
WARNING!
!
Lens Cleaning
1.
Remove the lens by unscrewing the four mounting screws.
2.
Using water and a soft cloth or Code 3 lens polish and a very soft paper towel or facial tissue, clean outer
surfaces of the lens and half filters.
3.
Plastic scratches easily, cleaning is recommended only when necessary about every six months.
CAUTION: Car wash brushes will scratch the lenses.
WARNING!
!
If attempting to clean the reflector, use only a mild glass cleaner and a very soft cloth. Do not
use any wax type cleaners as the wax will dull the finish and impair light effectiveness.
Lamps are extremely hot! Allow to cool completely before attempting to remove. Gloves and eye
protection should be worn when handling lamps. Accidental breakage can result in flying glass.
5.
Insert the replacement lamp assembly into the reflector. Twist clockwise 1/8 turn until you feel the locking
features of the socket engage.
6.
Test the lamp by connecting the lamp assembly to the cable. Switch the power source on. Verifying the
lamp is good, turn off the power source.
7.
Push the assembled AMP Mate-N-Lock connectors through the cut out in the vehicle for the reflector.
8.
Verify the "7021" product number on the reflector is on the top. Verify “TOP” lens engraving is on the top
of the lens. Mount the reflector and lens by installing the four screws.
