TABLE 3 - FLASHER TYPE
Features
360RS
360RD
360RDK 700
710/711
100W (2 lights),
X
X
Alternating Flash
200W (4 lights),
X
X
Alternating Flash,
Rear Only or Front
& Rear
200W (4 lights),
X
Alternating Flash
Rear Only, Front &
Rear, or Steady Burn
Front/Rear Flash
200W Heavy Duty
X
X
Alternating Flash
200W Heavy Duty
X
Programmed Flash
STOP/TURN/TAIL LIGHTS - Located in the upper or lower section of the light bar facing rear, one on the
driver side, one on the passenger side, these lights provide stop, turn and tail signals to following traffic when
connected to the vehicle lighting system. Lamps used are an 1157 bayonet type.
D.O.T. LIGHTS - A set of three marker lights as required by the Department of Transportation for truck
application. Lamps are wedge base '194' type.
FLASHER - Table 3 (below) shows the different models and their functions.
STROBE LIGHTING CONNECTIONS
Flash Patterns - All power supplies offer “Quad Flash” and “Random Flash”. The flash patterns are controlled
by jumpers on the power supply and can be changed by first removing the power supply from the lightbar and
then setting the jumpers. Refer to the following tables:
Rear Only Flash Pattern
Connect the RED and/or RED/BLK wire in the 16 wire cable to + 12 VDC through a user supplied
switch.
4/6 Head: Rear inboard and outboard strobes on each side will flash at a minimum rate of 70 FPM
(flashes per minute).
2 Head: If rear inboard strobes are present, strobes will flash at a minimum rate of 70 FPM.
Alternating Flash Pattern
Connect the RED and/or RED/BLK wire and the GREEN wire in the 16 wire cable to + 12 VDC through
a user supplied switch. This mode overrides REAR ONLY MODE.
4/6 Head: Front and Rear inboard and outboard strobes on each side will flash at a minimum rate of
70 FPM.
2 Head: If rear inboard strobes are present, strobes will flash at a minimum rate of 70 FPM.
Pursuit Flash Pattern
Connect the RED and/or RED/BLK wire and the GRN/BLK wire in the 16 wire cable to +12 VDC
through a user supplied switch. This mode overrides ALL OTHER MODES.
4/6 Head: Front inboard and outboard strobes on each side will flash at a minimum rate of 70 FPM.
2 Head: If front inboard strobes are present, strobe will flash at a minimum rate of 70 FPM.
6-Head Flash Patterns (FIG.18)
Quad
Random
Jumper
Quad
Random
J9
J36
J31
2 - 3
1 - 2
2 - 3
2 - 3
2 - 3
1 - 2
PSE 490E (FIG.18A)
YELLOW
Quad
Random
N/C
+12
4-Head Flash Patterns (FIG.20)
12
Jumper
