Code 3 LED X NarrowStik (Large Head) - Manual (Page 8)

8
Figure 8
BLUE
YELLOW
GREEN
VIOLET
GREY
ORANGE
BROWN
TAN
WHITE(2 REQ'D)
Front Facing System Wiring
CONT HD PWR (+12V)
OPTIONAL FRONT FACING MOUNTING
Large Split LED Narrowstik wire designations for optional front facing mounting
Blue
Yellow Grey Green Tan Violet Orange
Brown
Brown
Blue
DRIVER SIDE PASSENGER SIDE
Input Cables
RED, RED/WHITE Large Split Narrowstik® (+12V) wires (Both Input Cables)
WHITE DIM Control wire (Both Input Cables)
BROWN
ORANGE
Driver Side
TAN Input Cable
VIOLET
GREEN
No Connection
GREY No Connection
YELLOW No Connection INDIVIDUAL
BLUE No Connection LED MODULE CONTROL WIRES
BLUE (SEE FIGURE 8)
YELLOW Passenger Side
GREY Input Cable
GREEN
VIOLET
No Connection
TAN No Connection
ORANGE No Connection
BROWN No Connection
11-Wire Cable Wire Designations- Optional Rear Facing Mounting
