28
COMPRESSOR ELECTRICAL DATA
LEGEND
30HX UNIT
SIZE
VOLTAGE
V-Ph-Hz
COMPRESSOR
COMPRESSOR A COMPRESSOR B
RLA LRA (WD) LRA (XL) RLA LRA (WD) LRA (XL)
325
200-3-60 06TU483 409.0 938 N/A 409.0 938 N/A
230-3-60 06TU483 355.1 816 N/A 355.1 816 N/A
380-3-60 06TU483 216.7 494 1537 216.7 494 1537
460-3-60 06TU483 178.2 408 1270 178.2 408 1270
575-3-60 06TU483 141.0 326 1016 141.0 326 1016
325 HM
200-3-60 06TU483 519.2 1329 N/A 519.2 1329 N/A
230-3-60 06TU483 452.6 1156 N/A 452.6 1156 N/A
380-3-60 06TU483 273.1 700 2179 273.1 700 2179
460-3-60 06TU483 227.0 578 1800 227.0 578 1800
575-3-60 06TU483 180.8 462 1440 180.8 462 1440
350
200-3-60 06TU483 409.0 938 N/A 409.0 938 N/A
230-3-60 06TU483 355.1 816 N/A 355.1 816 N/A
380-3-60 06TU483 216.7 494 1537 216.7 494 1537
460-3-60 06TU483 178.2 408 1270 178.2 408 1270
575-3-60 06TU483 141.0 326 1016 141.0 326 1016
350 HM
200-3-60 06TU483 519.2 1329 N/A 519.2 1329 N/A
230-3-60 06TU483 452.6 1156 N/A 452.6 1156 N/A
380-3-60 06TU483 273.1 700 2179 273.1 700 2179
460-3-60 06TU483 227.0 578 1800 227.0 578 1800
575-3-60 06TU483 180.8 462 1440 180.8 462 1440
400
200-3-60 06TU554 462.8 938 N/A 462.8 938 N/A
230-3-60 06TU554 401.3 816 N/A 401.3 816 N/A
380-3-60 06TU554 242.3 494 1537 242.3 494 1537
460-3-60 06TU554 201.3 408 1270 201.3 408 1270
575-3-60 06TU554 162.8 326 1016 162.8 326 1016
400 HM
200-3-60 06TU554 591.0 1329 N/A 591.0 1329 N/A
230-3-60 06TU554 514.1 1156 N/A 514.1 1156 N/A
380-3-60 06TU554 311.5 700 2179 311.5 700 2179
460-3-60 06TU554 257.7 578 1800 257.7 578 1800
575-3-60 06TU554 206.4 462 1440 206.4 462 1440
HM — Heat Machine Units
LRA — Locked Rotor Amps
N/A — Not Applicable
RLA — Rated Load Amps
WD — Wye-Delta Start
XL — Across-the-Line Start
Electrical data (cont)
