FIELD-SUPPLIED AND FIELD-INSTALLED INSULATION

CONDENSER WATERBOX
INSULATION NEEDED (HEAT
MACHINE UNITS ONLY)

EVAPORATOR WATERBOX
INSULATION NEEDED

DISCHARGE PIPING
INSULATION NEEDED (HEAT
MACHINE UNITS ONLY)

NOTES:

1. Field-installed insulation for standard units shown in light gray.
2. Field-installed insulation for heat machine units shown in dark gray.
3. Back of the unit shown.

a30-4686
