8
Take Down and Alley Flash
Selecting Flash Patterns:
The Take Down and Alley Lights can be programmed to flash at different rates.
STEP 1:
Power-up the light bar. Select the Take Down Flash Mode (BLK) or the Alley Flash Mode (BLU/WHT) by applying +power to the appropriate wire. .
NOTE: Make sure +12v is only applied to the function you are trying to program - otherwise program function will not operate.
STEP 2:
Observe the flash pattern and determine which pattern is in operation (see Table 3). This table shows the available flash patterns. Once the flash
pattern has been determined, proceed to Step 3. NOTE: The default flash pattern for Take Down and Alley Lights is Medium Single 115FPM.
STEP 3:
Scroll to the next pattern by momentarily holding the BLK/RED wire to +power for ~one (1) second. The light bar will stop flashing when the wire
is connected to +power. Release the wire and the next pattern as listed in Table 3 will begin to flash. The new pattern is automatically stored each
time. NOTE: To restore the Factory Default Take Down and Alley Flash Patterns, hold the bLK/RED wire to +power for ~four (4) seconds.
TAbLE 3
TAKE DOwN AND ALLEY FLASh PATTERNS
PATTERN NUMbER PATTERN DESCRIPTION
1 FAST QUAD 80FPM
2 SLOW QUAD 60FPM
3 FAST SINGLE 375FPM
4 MEDIUM SINGLE 115FPM
5 SLOW SINGLE 60FPM
6 FAST DOUBLE 115FPM
7 SLOW DOUBLE 60FPM
8 FAST SIX 80FPM
9 SLOW SIX 60FPM
10 VARIABLE RATE SINGLE
11 NFPA QUAD 75FPM
12 CYCLE FLASH
