11

TRICORE® LIghT hEAD

TROUbLEShOOTINg gUIDE

Troubleshooting

All DEFENDER® Light bars are thoroughly tested prior to shipment. However, should you encounter a problem during installation or during the life of

the product, follow the guide below for information on repair and troubleshooting. Additional information may be obtained from the factory technical

help line at 314-996-2800.

Note: LED light heads must be replaced as a module. There are no user serviceable parts. warranty is void if module is disassembled

PRObLEM

QUESTIONS

POSSIbLE CAUSE

SOLUTION

TriCore Front Module

not operating

Are all heads out

in front or in back,

and not just a

single module out?

Yes

No

a. Front and/or Rear Cut Function powered

a. Defective module

b. Cable/Connector unplugged

a. Remove power (turn off) Front and/or Rear Cut

a. Replace module

b. Check cable & connector

TriCore Corner

Module has one

head out.

NA

a. Defective module

b. Cable/Connector unplugged

a. Replace module

b. Check cable & connector

Cruise Lights do not

operate

NA

a. No power on Cruise wire

b. Another Central Controller Function is on

a. Connect Cruise wire to switch

b. Turn off other functions

Any disassembly of any of the

TriCore®

light heads will result in loss of warranty coverage on the

equipment.

wARNINg!

Notes:
