LENS AND
ROTATOR
ASSEMBLY
SNAP-ON BLINDER
CORD AND PLUG
The Code 3 ® DashLaser ® is a powerful warning device that exceeds all minimum SAE Class 1 standards for 360°
warning lights. It is actually brighter than some "full-sized" light bars.
The DashLaser is a rugged unit, designed for long service life in interior or exterior applications. Each unit comes
with a snap-on, fast release blinder that is specifically designed for continuous use on the DashLaser without
causing damage to the device. A multipurpose mounting system is also standard.
Introduction
The use of this or any warning device does not insure that all drivers can or will observe
or react to an emergency warning signal. Never take the right-of-way for granted. It is
your responsibility to be sure you can proceed safely before entering an intersection,
driving against traffic, responding at a high rate of speed, or walking on or around traffic
lanes.
The effectiveness of this warning device is highly dependent upon correct mounting and
wiring. Read and follow the manufacturer’s instructions before installing or using this
device. The vehicle operator should insure daily that all features of the device operate
correctly. In use, the vehicle operator should insure the projection of the warning signal is not blocked by
vehicle components (i.e.: open trunks or compartment doors), people, vehicles, or other obstructions.
This equipment is intended for use by authorized personnel only. It is the user’s responsibility to understand
and obey all laws regarding emergency warning devices. The user should check all applicable city, state and
federal laws and regulations.
!
WARNING!
Code 3, Inc., assumes no liability for any loss resulting from the use of this warning device.
Proper installation is vital to the performance of this warning device and the safe operation of the emergency
vehicle. It is important to recognize that the operator of the emergency vehicle is under psychological and
physiological stress caused by the emergency situation. Warning devices should be installed in such a
manner as to: A) Not reduce the output performance of the system, B) Place the controls within convenient
reach of the operator so that he can operate the system without losing eye contact with the roadway.
Strobe power supply and flash tubes utilize high electrical voltages and/or currents. Properly protect and use
caution around live electrical connections. Grounding or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fire. Incandescent
lamps are extremely hot, allow to cool completely before attempting to remove.
Any electronic device may create or be affected by electromagnetic interference. After installation of any
electronic device operate all equipment simultaneously to insure that operation is free of interference. Never
power emergency warning equipment from the same circuit or share the same grounding circuit with radio
communication equipment.
PROPER INSTALLATION COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF EMER-
GENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF EMERGENCY PERSONNEL
AND THE PUBLIC.
Unpacking & Pre-Installation
YOUR DASHLASER COMES WITH THESE ITEMS
(OPTIONAL IN SOME SPECIAL PACKAGES)
Carefully remove the beacon and place it on a flat surface, taking care not
to scratch the lens. Examine the unit for transit damage, broken lamps, etc.
ADHESIVE PAD
TETHER CORD
4 ACORN NUTS
4 HEX-HEAD SCREWS
(one not shown)
FIGURE 1
