Jumper connector - the injectors are now connected directly to the sled’s ECU.
IV. Control Box Menus
1. Startup Screen
Every time the box is first turned on (by the engine or battery), the Startup Screen is displayed. Press any key to go to the
Main Menu. An example Startup Screen is shown below:
SkiDoo 600-1000
xxxxxxxx N2O:ADJ
.
In the example shown above, this screen displays the following information:
SkiDoo
Sled make
600-1000
Sled model Note: Be sure the Control Box is for your make and model of sled!
xxxxxxxx
Code Version This is the version of code in the box. The version of code can only be changed
by sending the box back to Boondocker.
N2O:
Shows that this Control Box is nitrous capable.
ADJ
Nitrous pressure regulator type (if used)
2. Main Menu
The Main Menu is shown below:
Main

Fuel Stats
Menu N2O Map1U
The current selection is shown by the Right-Arrow and the cursor (underscore below the “F”). Use the arrow keys to
move the cursor. Move the cursor to the desired selection and press the “SEL” key to select the desired menu option from
one of the following:
Fuel Go to the Fuel adjust menus.
Stats Display runtime data, captured data, and recorded maximum data.
N2O Menus for optional Boondocker Nitrous kit.
Map Go to the Map menu.
The current Map number is displayed as “Map1U”. This indicates that map number 1 is being used and it is Unlocked.
3. Fuel Adjust Menus
This selection is used to make fuel adjustments. There are up to seven Fuel adjust screens (examples shown below). Fuel
screen1 will be displayed after moving the cursor to the Fuel selection on the Main Menu and pressing the “SEL” button.
Go to the next screen by pressing the “SEL” button. After pressing the “SEL” on the last Fuel adjust screen, you will
return to the Main Menu. Use the Left/Right Arrow keys to switch between settings. Use the Up/Down Arrow keys to
change the setting values. Sample Fuel adjust screens are shown below (actual rpm settings and number of screens may be
different for your model).
Fuel screen1: M1L LO MD N2 DL
3000 00 00 00 00
Fuel screen2: M1L LO MD HI tr
5000 00 00 00 00
Fuel screen3: M1L LO MD HI tr
6700 00 00 00 00
Fuel screen4: M1L LO MD HI tr
7800 00 00 00 00
Fuel screen5: M1L LO MD HI tr
8100 00 00 00 00
Fuel screen6: M1L AM DR Sens
ACEL 00 00 00
The control box allows fuel adjustments to be made according to the following two factors: RPM and Engine Load.
