BoonDocker Turbo Z-1 GT28/60

Revised 06/05/09 Arctic Cat Z-1 GT28/60 Turbo Upgrade Installation instructions

Page 5

www.boondockers.com............................

BoonDocker

..........................................877-522-7805

Step 3 (continued): Install Turbo Charger

G. Install oil hose.

H. Install lower heat shield to header.

I. Install header.

J. Tighten turbo mount bolts.

K. Install upper heat shield.

L. Install oil drain.
