Model 6700 Family User’s Manual 5
Model 6702: 10.4 x 6.4 x 2.5
Model 6710: 10.4 x 10.4 x 2.5
Model 6720: 14.1 x 12.6 x 4.1
UL/CSA approved power supply with 6’ line cord
6702/6710: Wallmount
6720: In-line mounted below scale
Input: 120 VAC +10%-15%, Standard 3 wire
w/ground
Output: 15 VDC @.3 Amps DC
50/60 Hz selectable
0.1 amp maximum
42ºF – 104ºF (5ºC – 40ºC)
10% to 95% RH (non-condensing)
Models 6702/6710: Aluminum Base and Load
Bridge with stainless steel weigh platter.
Overload protection: Adjustable center and side
stops.
Model 6720: Die cast aluminum base with a
stainless steel weigh platter.
Overload protection: Adjustable center stop,
fixed corner stops.
½" high, six-digit LCD.
Key panel with ZERO and TEST keys.
Remote display with 7 ft. cable. Standard on
Models 6702 and 6710, optional on 6720.
Using the leveling bubble as a guide, adjust the
four adjustable feet to level the scale.
Initial automatic zero setting is ±10% of maxi-
mum capacity—active at power up. Manual zero
setting range is ±2% of maximum capacity—
active using the ZERO key.
Dimensions
Power Supply
Frequency
Power Requirements
Operating Temperature
Construction
Display
Scale Leveling
Zero Window
