Model 6700 Family User’s Manual 26
Scale is not transmitting data to the host
device
1. Check cable connection at both the rear
of the scale and the host device.
2. Check communication setting and baud rate
on both scale and software.
3. Perform I/O loopback test.
4. Replace the cable.
5. Replace the main board.
The ZERO key and the TEST key do not
function
1. Open display enclosure and verify that the
keypad cable is still installed correctly.
2. Replace the display panel.
3. Replace the display PCB.
4. Replace the display cable.
5. Replace the main PCB.
DESCRIPTION PART NUMBER
Keyboard Panel 56143-0018
Display PCB 7405-15465
RS-232 PCB 7405-14704-2
Power Supply - 6702/6710 1148-15535
Power Supply - 6720 1148-15536
RS-232 Cable - PC 1140-13842
6700-7 Kg (15 lb) Loadcell 7154-16323-07
6700-15 Kg (30 lb) Loadcell 7154-16323-15
6700-30 Kg (60 lb) Loadcell 7154-16323-30
6700-60 Kg (120 lb) Loadcell 7154-16323-50
Remote Display Kit
7300-16577-04
Remote Pole Kit 7200-14837
Remote Pole/Displ Kit 7’ 7300-16864-03
Remote Pole/Displ Kit 14’ 7300-16864-04
6702/6710 Fr/Rear Mt. Bkt. 7200-14829
6700 Foot 7075-10256
6702/6710 Frt Mt. Bkt. 1067-17061
Spare Parts Listing
