Model 6700 Family User’s Manual 19
The Calibration (CAL) Mode menu lets you
calibrate your scale. The items in the calibration
menu are as follows:
POUNDS/KILOGRAMS (LBS or 1000 Gr) –
Selects the unit of measure of your calibration
test weights (lb or kg).
CAPACITY (9.995, 15.005, 30.01, 60.02 etc.) –
Select the capacity of the scale.
Follow these steps to calibrate the scale. Refer
to Figure 3.
1. From the DIAG display, press the ZERO key
until CAL is displayed, or from the normal
weighing mode, move Switch 1 to the Menu
mode or OPEN position. Press the ZERO
key until CAL is displayed.
2. Press the TEST key…
50 H or 60 H is displayed. This is the AC
line frequency.
3. Press the ZERO key to toggle between the
choices. When the choice you want is
displayed, press the TEST key…
That choice is accepted and LBS or
1000Gr is displayed.
4. Press the ZERO key to toggle between the
choices. When the choice you want is
displayed, press the TEST key…
The scale capacity is displayed.
(Example: 9.995)
If a different capacity selection is de-
sired, press the ZERO key to scroll
through the choices.
Calibration Mode
Step-by-Step
Instructions
for CAL Mode
