Salter Brecknell 630 User Manual
Page 23
xxiii
B.1.3.2
CONTINUOUS MODE
The Demand mode is used to interface to computers, scoreboards and other remote devices
requiring constant data updating. The transmission occurs at the end of each display
update. Figure B-6 shows the serial data format for the Continuous Mode.
Polarity:
"–" = Negative
Weight Data
Units:
L = pound
K = kilogram
Gross/Net:
G = Gross
N = Net
Start
Transmission
Carriage
Return
Line
Feed
Status:
M = Motion
O = Over/under range
FIGURE B-6. Consolidated Controls Continuous Mode
B.1.4
TRANSMIT APW MODE
The Transmit APW Mode is designed specifically for connection to any of the following TC
Series scale models:
•
Its purpose is to allow APW’s derived on the 630 scale to be transmitted to a larger scale for actual
piece counting there. Just press the PRINT key at any time on the 630 to initiate the
transmission. Consult your SXXX, SXXX or SXXX scale manual for more information.
