B.1.2 DEFAULT PRINT FORMAT
Figure B-4 shows the fixed format of the print format. NOTE: The TARE and NET fields are blank
when a tare has not yet been established in the system. The PCS field is blank when
an APW has not yet been established in the system.
ID. NO. 123456
GROSS 5.000 LB
TARE 1.480 LB
NET 3.520 LB
PCS 3520
FIGURE B-4: Default Print Format
B.1.3 FULL DUPLEX MODES FOR COM1
B.1.3.1 DEMAND MODE
The Demand mode allows control from a host device, usually a PC, and can be activated by
pressing the Print key. Figure B-5 shows the serial data format for the Demand Mode.
Table B-1 shows the recognized host commands.
xxxxx.xx
Polarity:
= Positive
"–" = Negative
Weight Data
Units:
lb = pound
kg = kilogram
Gross/Net:
GR = Gross
NT = Net
Start
Transmission
Carriage
Return
Line
Feed
Space Space
FIGURE B-5. Consolidated Controls Demand Mode
“P” - This command is sent to the scale to print the indicated display. The scale will
not respond if the scale is in motion, positive overload or negative overload.
“Z” - This command is sent to the scale to zero the scale. If the scale is in motion,
the scale will wait until a state of equilibrium is achieved. The scale will not
respond at all if the scale is in positive overload or negative overload.
“T” - This command is sent to the scale to tare the scale. If the scale is in motion,
the scale will wait until a state of equilibrium is achieved. The scale will not
respond at all if the scale is in positive overload or negative overload. The
scale will also not respond if it displaying a negative gross value.
“C” - This command is sent to the scale to toggle among the configured units.
TABLE B-1. Recognized Host Commands
