viii
CHAPTER 3: OPERATION
3.1 DISPLAY
The Model S610 scale utilizes a 6-digit LED (LIGHT EMITTING DIODE) screen to display the weight
and system information.
3.1.1 LIGHT EMITTING DIODE (LED) DISPLAY
Figure 3-1 shows the display detail of the LED display. Table 3-1 lists the various annunciators you
may see and their meanings.
FIGURE 3-1: S610 Display Detail
Annunciator MEANING
TARE Indicates that a tare has been established in the system.
WT Indicates that the displayed value is weight.
PCS Indicates that the displayed value is the number of pieces currently on the platform. If
a tare has been established, the scale will indicate the NET number of pieces.
APW WT Indicates the Average Piece Weight of the pieces on the platform.
TARGET Indicates that a value for check weighing has been entered.
TABLE 3-1: S610 Series Annunciator Definitions
