xxii
B.1.3.2 CONTINUOUS MODE
The Demand mode is used to interface to computers, scoreboards and other remote devices
requiring constant data updating. The transmission occurs at the end of each display
update. Figure B-6 shows the serial data format for the Continuous Mode.
xxxxx.xx Units
Polarity:
= Positive
"–" = Negative
Weight Data
Units:
L = pound
K = kilogram
Gross/Net:
G = Gross
N = Net
Start
Transmission
Carriage
Return
Line
Feed
Status:
= Valid
M = Motion
O = Over/under range
G = gram
FIGURE B-6. Consolidated Controls Continuous Mode
B.1.4 TRANSMIT APW MODE
The Transmit APW Mode is designed specifically for connection to any of the following TC
Series scale models:
• S630
• S650
Its purpose is to allow APW’s derived on the S610 scale to be transmitted to a larger scale for actual
piece counting there. Just press the PRINT key at any time on the S610 to initiate the
transmission. Consult your S630 or S650 scale manual for more information.
