xvi
NAME/CO
DE
DESCRIPTION CODE/VALUE
A1
Baud Rate
Selects the baud rate for data transmission through the serial port. 1200 2400
4800 9600√ √√√
A2
Data Bits and
Parity
Selects the number of data bits and parity of serial transmission.
"8n" = 8 data bits with no parity bit
"7O" = 7 data bits with odd parity bit
"7E" = 7 data bits with even parity bit
8n√ √√√
7O
7E
A3
Mode of Serial
Transmission
Selects when data will be sent out of the serial port to a printer or
computer:
"C" = Continuous mode; send data continuously
"d" = Demand mode; send data when a PRINT command is issued
from the printer, computer, or indicator.
C
d√ √√√
A4
Display Check
Actuates the function that illuminates all digit segments, decimal
points, and LED annunciators in a test sequence. Pressing the 6 key
to scroll down one level begins the test sequence.
Press 6 key to
begin sequence
A6
Serial Port
Mode
Selects the mode of the RS-232C serial port:
"0" = Full Duplex Mode
"1" = Print Ticket Mode
"2" = APW Transmit Mode
0
1
2√ √√√
A7
ID No. Enable
Allows the ID No. to be disabled in the printout. Valid only when A6 is
set to “1”.
"0" = Disable the ID No. "1" = Enable the ID No.
0√ √√√
1
A8
ID No. Entry
Actuates the function that allows entry of a new ID No. Valid only
when A6 is set to “1”. Pressing the 6 key to scroll down one level
begins the sequence.
0 - 999999
(123456 is default)
A9
No. of Line
Feeds
Actuates the function that allows entry of the desired number of line
feeds to be printed after the printout. Valid only when A6 is set to “1”.
Pressing the 6 key to scroll down one level begins the sequence.
0 – 99 (5 is
default)
Table 5-1: User Menu Descriptions
5.4 USER MENU PROCEDURES
This section provides instructions for all of the User Menu procedures.
5.4.1 ID Number Entry (A8)
1. While in the User Menu mode, scroll to " A 8 ", then scroll down once using the 6 key
to enter the ID Number menu.
2. The display will momentarily show " ET ID ", followed by the current ID number value.
3. Use the front panel numeric keys to key-in the actual ID Number value. If you make
a mistake, press the CLEAR key to clear your entry and start over.
4. After entering the exact value, press the SAMPLE / SAVE key to save the ID
Number value. The display will show " END ID " momentarily, then revert back up to
A8.
