22 B140 Counting Scale User Instructions
6. The scale will not accumulate more than 999 times or 999999 counts. If this
occurs the display will show ERR01. This means the display is over range.
3.3 RS232 Interface and RTC (Real Time Clock)
The RS232 interface is optional. When it is installed current data can be sent to this
port by pressing the Print key. The hardware real time clock (RTC) and backup battery
are also optional. If the RTC is installed, you only need to modify the date and time
when they are not correct. If RTC is not installed, a software RTC can be used. You
need to set the date and time every time the scale is reset. If the scale’s ID, date or time
are active, they can be printed out. The format is similar to the examples below:
3.3.1 In General Counting Mode:
ID: 123456
Date: 2012-05-16 ;(YYYY-MM-DD)
Time: 16:23:53 ;(HH:MM:SS)
Gross: 12.5675kg
Tare: 0.0675kg
Net: 12.5000kg
Merchandise: PLU1 ;(PLU1,PLU2...PLU8, Tmp)
Piece Weight: 0.0005kg
Count: 25000pcs
3.3.2 In General Counting and Display Accumulation Mode:
Scale ID: 123456
Date: 2012-05-16
Time: 16:23:55
Merchandise: PLU1 ;(PLU1,PLU2...PLU8, Tmp)
Piece Weight: 0.0005kg
Add number: 12
Total Count: 25000pcs
(1) Remove the counted items from the scale and let the scale return to a stable
condition before you count more items and perform the next accumulation.
(2)There are nine accumulator memories for nine different items; PLU1 - PLU8 piece
weight channels and a temporary piece weight. That means different piece weights
have their own accumulator memory.
