Page 8
6
Power over Ethernet Connection
Box type camera is fully complied with PoE standard. It allows you to use PoE enabled switch or PoE
injector to transmit data and power thru single Ethernet cable.
PoE Enabled Switch Connection Diagram
PoE Switch
PoE Injector Connection Diagram
Ethernet Switch
PoE Injector
Power cable
Wall outlet
RJ45 LED
LED
Status
Blinking Green
Connected to 100 Base-T mode and also transmitting and receiving data.
Steady Yellow
Connected to the Internet.
