8
Adjusting the CS-mount Ring
1 . Unplug the CS-mount lens cable from the
socket.
2. Unscrew the CS-mount lens
counterclockwise.
3. Place one lens ring pad.
4. Screw the CS-mount lens and connect the
CS-mount lens cable to the socket. Check if
the IP camera can display proper image. If
not, repeat step 3 and 4 to add the next ring.
If all the rings are used up and still the IP
camera cannot display proper image.
Remove all the rings and continue to next
step.
5. Using the L-type hex wrench loosen the bolt
underneath the IP camera.
