CS-Mount Lens
(1)
(3)
(2)
(1) Zoom controller
(2) Focus controller
(3) DC-Iris control cable
IP Camera Installation
This section provides useful tips on how to adjust the IP camera to meet your needs.
Connecting the Lens
1. Screw in the CS-mount lens clockwise to
the CS-mounting ring. Make sure the lens
adhesive cover is removed when using it for
the first time.
2. Connect the CS-mount lens cable to the
socket.
