AVer Box type IP cam(E) Installation Guide - Manual (Page 13)

11
ENGLISH
Technical Specifications

FX2000 (E)/FX3000-R (E)
Model FX2000 (E) FX3000-R (E)
Len spec. Computer AG3Z3112FCS-MPIR (Optional)
lens type vari-focal Lens (CS mount)
F/no F/1.2
Iris type DC-Iris
focal length f3.1~8mm
View Angle
H 99°(W)~42.8°(T)
V 52.7°(W)~23.2(T)
H 93.6°(W)~34.4°(T)
V 63.4°(W)~24.2(T)
MFZ Support N/A
Camera image
Min. illumination
0.15 Lux@F/1.2 in day mode
(color)
0.001 Lux@F/1.2 in night mode
(B/W)
0.15 Lux@F/1.2 in day mode
(color)
0.0015 Lux@F/1.2 in night mode
(B/W)
Built-in LED No
IR distance No
Built-in mechanical ICR Yes
Auto IRIS Yes
Video
Compression H.264/MPEG-4/MJPEG
Max. resolution 1920 x 1080 2048 x 1536
Frame rate 1920 x 1080 @ 30fps
2048 x 1536 @ 20fps
(Wide Angle)
1920 x 1080 @ 30fps (Normal
mode)
H.264/MPEG-4
bit rate mode
VBR, 5 levels
CBR, 64/128/512/768Kbps & 1/2/3/4/6/8/10/12Mbps
MJPEG quality 5 levels
Regional of Interest Yes
