AVer Box type IP cam(E) Installation Guide - Manual (Page 15)

13
ENGLISH
Model FX2000 (E) FX3000-R (E)
Event
Profiles 32 sets
Triggers
Alarm Interval, Motion Detection Region, Digital Input, SD Card,
Network
Actions
Trigger: Digital Output, Alarm Audio
Send out video clip: FTP, NAS, SD card
Send out snapshot / log: FTP, NAS, SD card, mail
Interface
Digital input/output 1/1
BNC Video output Yes
Built-in storage option SDHC & SDXC card (64GB max.)
Built-in micophone Yes
External microphone input Yes
External Audio output Yes
RS-485 Yes
General
Power supply DC 12V(2A)/PoE
Power consumption
DC: 5.0W (TYP)
POE: 6.5W (TYP)
PoE PoE Class 3 (IEEE802.3af)
Dimensions 165.05mm x 58.6mm x 69mm (L x H x W)
Net weight 490g (w/o bracket)
Temperature and humidity 0°C~50°C, 20%~90%
Software Requirement
OS Windows® XP/7/8
Browser
IE 8/9/10/11 (Full Function), Chrome
Firefox and Safari (Basic Function)
Firmware remote upgrade Yes (via HTTP)
