AVer FX3000R - Manual (Page 6)

2
Name Function
(3) Video screen Change the video screen display.
Display the actual video pixel size.
Display the video screen in compact size.
Display the video on the entire screen. Press ESC to exit full
screen mode.
(4) Stream Switch to view the video stream type. The IP camera can send
multiple video streams of up to 3 types. To change the video stream
setting, go to System > Video Stream.
(5) Direction buttons - Use to move the position of the view point while in zoom mode.
- Use to control the position of the RS-485 pan tilt device
(6) Pan & Patrol button Pan: automatically move the view point from left to right when in
zoom in mode.
Patrol: automatically move the view point around the preset locations
in Application > Patrol.
(7) Digital /RS-485 - Select Digital to control the IP camera ePTZ operation. This
allows you to closely view the target area without having to
physically move the IP camera. The image will be zoomed in and
you can use the direction control to pan the zoomed image.
- Select RS-485 to control the PTZ driver or scanner via RS-485
connection to I/O terminal block. The IP camera is mounted on
an RS-485 pan tilt device.
(8) Speed control Set the speed when panning, tilting, or zooming.
(9) MFZ function
Motorized focus and zoom the IP camera(see aslo Using MFZ
Function )
(10) Zoom control Reset zoom level.
Increase zoom level.
Decrease zoom level.
(11) Quick Focus
It help user to adujst foucs of IP camera more easily(see aslo Using
Quick Focus ).
(12) Capture Capture and save the image on the screen in *.bmp format.
