15
QUICK USER GUIDE
Name Function
(4) EMap Display the map in each area, and the location of camera/ sensor/ relay
and the warning.
(5) Network Enable/disable remote system access. This feature allows you to access
DVR server from a remote location via internet connection. The default is
disabled.
(6) Setup Configure the system settings.
(7) PTZ Access PTZ control panel.
(8) Preview Switch to Preview mode. This allows you to view live camera display.
(9) Playback Switch to Playback mode. This allows you to view the recorded video file.
(10) Status bar Display the current date, time, hard disk free space and temperature of
unit.
(11) Camera ID Show the number of cameras that are being viewed. When you are in
single screen mode, click the camera ID number to switch and view other
camera.
(12) Snapshot Capture and save the screen shot in *.jpg format.
i
Please plug the USB pen drive to DVR server before press Snapshot button.
(13) Event log Show the record of activities that take place in the system.
(14) AutoScan Start/Stop video screen cycle switch.
(15) Full screen View in full screen. To return, press the right button of the mouse or ESC on
the keyboard or click the arrow icon.
Click to exit from
full screen mode
When you switch to full screen in multiple-screen mode, Left click to toggle
to only display one of the video in the multiple-screen mode or all.
(16) Alarm Alert and display warning info.
(17) Virtual Click to enable virtual keyboard.
