TOOLS AND MATERIALS REQUIRED
PROVIDED HARDWARE
ITEM HARDWARE QTY
10 WALL PLUG 4
11 SCREW CAP 4
12 SELF DRILLING SCREW 3
13 SELF-DRILLING SCREW 3
14 FLAT HEAD SCREW 1
15 CLEAR SETTING BLOCK 2
16 CLEAR SETTING BLOCK 2
PENCIL
DRILL MALLET HAMMER SILICONE SCREWDRIVERS
CUTTING PLIER LONG NOSE LOCKING PLIER LEVEL WOODEN BLOCK TAPE MEASURE
10 11 12 13 14 15 16
If the shower panels are to be assembled on ceramic tiles, use a 1/4˝ drill bit for ceramic tiles.
1/4˝ & 1/8˝ DRILL BITS
*
*
2 ˝
6 ˝
1/2
˝
