INSTRUCTION MANUAL
Table of Contents ●
MODEL NUMBER ............................................... 2
GENERAL INSTRUCTIONS .................................... 3
INSTALLATION OVER CERAMIC TILES ....................... 3
NOTICE ......................................................... 3
CARE FOR YOUR FRAMELESS SHOWER DOOR ............. 3
PARTS LISTING ................................................. 4
PROVIDED HARDWARE ........................................ 5
TOOLS AND MATERIALS REQUIRED ......................... 5
1. MOUNT THE WALL JAMB. ................................ 6
2. FASTEN THE “U” CHANNEL. ............................. 7
3. INSTALL THE FIXED PANEL. ............................... 8
4. INSERT THE FIXED PANEL GASKET. ...................... 8
5. INSTALL THE HINGES. ..................................... 9
6. FASTEN THE SUPPORT BAR. .............................. 9
7. INSTALL THE DOOR PANEL. .............................. 10
8. SILICONE SEAL THE EXTERIOR. ......................... 11
General Instructions ●
- Read this manual carefully and completely before
proceeding.
- It is recommended that you wear safety glasses at all
times during the installation.
Installation over Ceramic Tiles ●
- Silicone should be used to seal the gap where the
ceramic tiles meet the fixed panel.
- If your shower door is to be installed over ceramic tiles,
the tiles should lay completely under the wall jamb.
Notice ●
- Caulking: no sealant is required inside the shower.
- All models are equipped with transparent sealing
gaskets.
Care for your Frameless Shower Door ●
- Never use scouring powder pads or sharp instruments on
metal pieces or glass panels.
An occasional wiping down with a mild soap diluted
in water is all that is needed to keep the panels and
aluminum parts looking new.
- We recommend wiping the glass panels with a squeegee
after each use.
Product specifications are subject to change
without notice.
