nstallation
Normal Tap without thread & screw type inlet hose
1.
Unscrew the fixing screw to
attach the tap.
2.
Push the connector up tiil the
rubber packing is in tight contact
with the tap. Then tighten the 4
screws.
3.
Push the water suppiy hose
verticaiiy upwards so that the
rubber packing within in the
hose can adhere completeiy to
the tap and then tighten it by
screwing it to the right.
Normal Tap without thread & one touch type inlet hose (Single inlet models)
1.
Untighten the upper connector
screw.
2.
Push the upper connector up tiii
3.
Connect the water supply hose
• in case the diameter of the tap is
iarge remove the guide piate.
Guide plate
Cotttteclor
the rubber packing is in tight
contact with the tap. Then
tighten the 4 screws.
Rubber packing
Middle
connector
• Turn the middie connector not
to have water ieaked.
• Make sure that the rubber seai
is inside the hose connector.
to the middie connector,
pushing the piate down.
• To separate the water suppiy
hose from the middie connector
shut off the tap. Then puii the
inlet hose down, pushing the
piate down.
• Make sure that there are no
kinks in the hose and that it is
not crushed.
8
