B.FOE LINE TMMMEB USE
A WARNING
The
plastic
shieM
must
be
properly
installed
for
all
Ime
trimmer
usage.
The
plastic
shield
pro
vides
partial
protection
&om
the
risk
of
thrown
objects
to
the
operator
and
others
and
is
equipped
with
a
line
limiter
which
cuts
excess
line to the proper length. ____________________________
A WARNING
Failure
to
install
shield
in
the
position
shown
can
result
in
serious
iipjury
to
the
oper
ator.
The
length
of
the
shield
must
be
aligned
with
the
len^h
of
the
drive
shaft
housing.
Di
rect the widest part of shield toward the engine
NOTE; Remove the metal shield md blade before
inatAlling the plastic shield and tnmmer head.
1. Place the shield under the bearing housing and
align screw holes. __________ ''
■
r.AtmONTl The line limiter (on the underside of
the shield) is sharp and can cut you. .
2. Insert screws “D.” through the bearing housing
into the shield. ^
Tighten the screws evenly and securely.
Remove the packing cover from the arbor shaft if so
equipped.
Install grass washer “K.” over the arbor shaft. Make
sure the grass washer is against and curved over the
dust cup. _ . ,
Start threading the trimmer head onto the arbor
shaft.
^
.
.
Align the hole in the dust cup with the hole in the
center front of the bearing housing by turning the
dust cup. Then, insert the small hex wrench (pro
vided) into the migned holes to keep the arbor shaft
from turning.
.
3.
4.
6
.
7,
8.
Tighten the trimmer head agEunst the washer and
dust cup while holding the hex wrench.
9.
Remàve the Hex wrench.
NOTE;
To
remove
the
trimmer
head,
insert
the
hex wrench into thè aligned holes in the dust cup
and hearing housing. Unthread the trimmer hean.
Be sure to store ^ass washer “K.”, plastic shield, 4
shield screws, and hardware with the trimmer head
for future use.
