CRAFTSMAN 4-CYai ENGINE
MODEL;143.816012
Eef.
No.
Part
No. Part Name No.
Part
No, Part Name
281 33013 Cover, Starter hole
340 34155 Bracket, Fuel tank
282 6507«) Screw, Pan hd. taptite, 8-32 x 3/8
342 650561 Screw, Hex washer hd. Duriok, 1/4-20
285 jöZß/ Hub, Starter
x5/8
286 llRddñ
VívTTTT»«*
Screen, Starter
345 341S4 Plate, Fuel tank mounting
287 29752 Nut & Lockwasher, 1/4-28
3«) 570682 Primer Assy,
2S0 3070S Lina, Fuel
351 Line, Primer
232 26460 Clamp, Fuel fine
355 590574 Starter Handle, Mitten grip
238 fld^CJCSCl
V j ?T k . Jt .if k T
Screw, Hex washer hd* thread cutting,
364 33377 Bracket, Carburetor cover mounting
1/4-15x7/8 ■
365 650767 Screw, Hex washer hd. Sems, taptite.
300 34156A Tank, Fuei Unci. Nos 292 & 301) 8-32 X 27/64
301 35355 Cap, Fuel tank
370 3^8 Decal, Instruction
30S 35SS4 Tube, Oil fill
370B zmn Decal, Choke
306 35499 "0" Ring
370C 34144 Decal, Primar
3u8 35540 Clip, Fill tube
^2370A Carburetor (Inct. No, 224)
310 35555 Dipstick, Oil
390 590630 Starter, Rewind
314 650873 Screw, Hex hd.. Sams, 1/4-20 x 3/4
396 Electric Starter Kit No, 143.88924 (Op-
316 611111 Coil Assy., Alternator (18 Watt)
tional) Order as Accessory.
322 611118 Body Connector
4(K) 33279Q Gasket Set Unci, items marked *j
325
0044^
Ä.^'T'TW
Clip, Spring
3S392A Plug, Starter RPM Settings:
328 35^ Key, Ignition High Speed; 3^ - 3850
323 61(^^ Tertninai Assy. Low Speed: 17«)
330 35305 Wire, Ground
336 650765 Screw, Hex washer hd, self-drilling. *indicates Parts Included in
10-32 X 1/2 "
Gasket Set, Ref. No. 400.
337 35057A Cover, Carburetor
338 28942 Screw, Hex washer hd Sems, 10-32x
3/8
1
CARBURETOR NO. 632370A
^ yj
J i t « p i
1
® I !
24 “
-25
Ref.
No,
Part
No.
Part Name
632370A Carburetor
1 631776A Shaft & Lever Assy., ThroUle
2 631970 Spring, Throttle return
3 631778 Shutter, Throttle
4 650506 Screw, Throttle & Choke shutter
5 630766 Spring, Regulating screw
5Ä 630738 Spring, Main adjustment screw
6 650417 Screw, Idle regulating
7 632112 Shaft B Lever Assy., Choke
8 630735 Spring, Choke positioning
9 632174 Shutter, Choke
10 •630748 Plug, Welch
11 •631027 Plug, Welch
12 *631021 Inlet Needle, Seat & Clip Assy
(IncL No. 13)
13 ^1022 Clip, Inlet needle
14 №019 Float, Carburetor
15 •631024 Shaft, Float
16 631951 Bowl, Float (Inci, Nos. 17 & 18)
17 27136A Plunger Assy , Drain (Ind, No, 18)
18 27554 Gasket, Drain
20 •632239 Adjustment Screw Assy., Main
Unci. Nos. SA, 21, 23 & 27)
21 27110 Gasket, Bowl-to-body
23 *630740 "0" Ring, Adjustment screw
24 6322B1 Screw, Idle adjustment
25 *631028 Gasket, Bowl-to-body
26 632164 Fitting, Fuel inlet
27 630739 Washer
28 632347 Repair Kit (Inc!, items marked *)
