CRAFTSMAN 32” TRAC-PLUS SNOW THROWER 536.885020
rjjptr
NO,
PART NO. PART NAME
1 3535 Cap, Push, 5/6 In.
2 70985 Screw, 5/16-18
X
3/4 In.
3
\5viOO
Pivot Pin
4 310421 Support, Control Panel Assembly
5 4049 Bumper
6 308012 Upper Handle
7 £rOD£?4
OJuO 1
Control Knob
a
70990 Screw, 5/16'18
X
1*3/4 In.
9 309793 Socket, Headlight
10 308037 Shift Lsvcr
11 71071 Flatwasher, 11/32 in
12 71059 Lockwasher. 1/4 In.
13 71034 Hex Nut, 1/4-20
14 306523 Control Panel
15 310391 Carriage Boll, 1/4-20 x 2 In.
16 71042 Hex Nut, 5/16-24
17 71060 Lockwasher, 5/16 In
18 50782 Ball Joint
19 6352 Adaptor, Speed Control Rod
20 50786 Spring
21 71072 Flatwasher, 3/8 In,
22 71038 Locknut, Hex, 5/16-18
23 1668 Rod, Speed Control
24 1578 Clutch Cable
25 7288 Screw, 3/8-16 X 3 !n.
26 71062 Lockwasher, Spirt, 3/8 in
27 71044 Hex Nut, 3/8*16
28 7289 Plastic Stop, 3/8 In.
29 71045 Nut, Hex Jam, 3/8-16
30 71457 Eye Boil, 3/8-16x5 In.
31 308789 Decal, Control Pane!
32 307913 Lower Handle
33 1671 Spring, Drive Clutch
34 1673 Spring, Auger Clutch
35 71035 Locknut, 1/4-20
36 304872 Retainer Ring
37 307399 H^ndte, Chut© Cr©nk
38 85192 Crank Assembly
39 148 Grommet, Eye Bolt
*40 71081 Cotter Pin, 3/32
X
3/4 In
REF.
NO.
PART NO.
PART NAME
41 104 Plastic Cap
4-2 7055 Rod, Chute Control
43 7058 Jam Nut, 1/2-20
¿ 1.4 7059 Lockwasher, Split. 1/2 in.
45 70993 Carriage Bolt, 5/16-18 x 3/4 In
46 7052 Bracket, Chute Rotate L H
47 7053 Bracket, Chute Rotate R H
48 71037 Hex Nut, 5/16-18
49 580527 Saddiewasher, 5/16 In.
50 71007 Hex Head Bolt, 3/8-16x2 in,
51 3903 Auger Drive Control Decal
52 3902 Traction Drive Control Decal
S3 6300 Gear Selector Decal
54 309344 Adaptor For Boot
55 308145 Eyebolt Bool
56 309312 Flatwasher, 3/8 In
57 308146 Clutch Spring Boot
58 307395 Upper Housing, Headlight
59 305025 Headlight Assembly
60 580530 Lower Housing, Headlight
61 307781 Screw, #10 X 1-3/4 In
62 307767 Wiring Harness
63 580532 Bracket, Headlight Mounting
64 4160 Bolt, Carriage, 5/16-18 x 1-3/4 in
65 30Э792 Metaiized Back
66 71061 Washer, External Lock
67 71046 Locknut, Nylon, 3/8-16
68 6636 Conduit, Plastic
69 235 Screw Hex Head, 5/16-18 x 2 In
70 308909 Screw, 10-24 X 5/8 in
71 309789 Lens. Headlight
72 309791 Bulb. Headlight
73 307918 Auger Drive Lever
74 307920 Traction Drive Lever
75 57444 Cable Tie
76 307251 Owner's Manual
