CRAFTSMAN 32" TRAC-PLUS SNOW THROWER 536.885020
REF.
NO. PART NO. PART NAPE
REF.
NO. PART NO. PART NAME
1 1065 Seai 16 53733 Flatwasher, 7/8"
2 895 Housing L.H, 17 50795 Key, Hi-Pro 606
3 53743 Bearing, Auger Gear Box 18 53732 Worm Gear
4 20556 Square Key 19 50683 Flatwasher
5 53748 Flatwasher. Г 20 50688 Ring Retainer
6 73905 Woodrulf #91 Key 21 53731 Bearing. Impeller Shaft
7 53730 Worm Gear 22 53749 Grease Plug
8 897 Gasket, Gear Box 23 1401 Shaft, Gear Box Input
9 73826 Locknut, 1/4-20 24 307909 Impeller
10 1403 32" Auger Shaft 25 896 Housing R H.
11 1441 Screw. 5/16-24 X 1-3/4" 26 71393 Screw, 5/16-24 X 1"
12 53737 Ring Quad 27 71100 Flange Locknut, 5/16-24
13 53736 Bearing, Impeller Shaft 28 73839 Screw, 1/4-20 X 2-1/4"
14 53735 Flatwasher, 7/8" 29 71067 Flatwasher, 1/4"
15 53734 Bearing, Rolier
38
