CRAFTSMAN 8HP MODEL 987.889000 REPAIR PARTS
DRIVE ASSEMBLY
Ref. Part Description Qty.
1 * Engine, 8 HP................................... ...... 1
2 1769904 Engine Pulley.................................. ...... 1
3 1100243 Lock Washer, 3/8............................. ...... 1
4 1915933 Bolt. 3/8-24x1-3/4-Grade 8................ ...... 1
5 1773599 Washer, Nylon................................. ...... 1
7 1915475 Warning Decal................................. ...... 1
8 1766326 Oil Valve Cap.................................. ...... 1
9 1768865 Oil Valve (Incl. Ref. 8)...................... ...... 1
10 1909371 Oil Drain Hose................................. ...... 1
11 1186393 Flange Locknut, 3/8-16..................... ...... 5
12 1727379 Pop Rivet, 3/16............................... ...... 4
13 1769870 Flap.............................................. ...... 1
14 1769869001 Flap Bracket................................... ...... 1
15 1769885 Lower Transmission Rod.................... ...... 1
16 1185147 Cotter Pin, 3/32x5/8........................ ...... 8
18 1890234 Flat Washer, 1/2............................. ...... 1
19 1107382 Flat Washer, 5/16............................ ...... 5
20 1711864 Compression Spring.......................... ...... 1
21 1763219 Shoulder Bolt.................................. ...... 1
23 1715538 Nyliner, 1/2.......................................... 2
25 1748393 Carriage Bolt. 3/8-16 x 1-3/4............. ...... 1
26 1764920 Idler Arm ...................................... ...... 1
27 1756151 Idler Pulley............................................ 2
28 1107383 Flat Washer, 3/8............................. ...... 3
29 1715685 Plastic Grip.................................... ...... 1
30 1733398 Top Locknut, 3/8-16................................ 1
31 1915831 Lift Crank Assembly......................... ....... 1
32 1100086 Bolt, 3/8-16x1-3/4.................................. 1
33 1186389 Flange Locknut, 1/4-20.................... ....... 4
36 1100243 Lock Washer, 3/8............................ ....... 1
39 1186347 Flange Lock Screw, 3/8-16 x 1........... ....... 4
41 1769881 Interlock Cam................................. ....... 1
42 1769877 Lower Brake Rod............................. ....... 1
43 1702646 Washer, Flat 1/2............................. ....... 3
44 1770361 Interlock Latch............................... ....... 1
48 1725264 Swivel Block................................... ....... 2
49 1186258 Jam Nut. 5/16-18............................ ....... 2
50 1185388 Retaining Ring................................ ....... 2
51 1708012 Flat Washer................................... ....... 4
53 1701447 Special Washer............................... ..... A/R
54 1769781 Square Key, 3/16 x 2-1/2.................. ....... 2
55
*
Transmission Assembly (Model 915-029) 1
56 1104436 Woodruff Key, 3/16x3/4................... ....... 1
57 1732499 Top Locknut. 5/16-18...................... ....... 4
* See parts breakdown In this Section.
A/R As required.
N/l Item not included with unit; order separately.
Ref. Part Description Qty.
58 1770247 Lower Blade Rod......................................... 1
60 1770326 Transaxle Pulley......................................... 1
61 1118808 Retaining Ring............................................ 1
62 1107381 Flat Washer, 1/4......................................... 3
63 1100002 Screw, 1/4-28x3/4...................................... 1
64 1186391 Flange Locknut, 5/16-18............................... 1
65 1110108 Locknut, 3/8-16.......................................... 1
66 1100241 Lock Washer. 1/4........................................ 1
67 1100043 Screw. 3/8x1-1/4........................................ 1
68 1769888 Upper Blade Rod......................................... 1
69 1768140 Transmission Arm........................................ 1
70 1767837 BaItJoint.......... :........................................ 1
71 1768628 Shift Link Rod:............................................ i
72 1769873 Upper Transmission Rod............................... 1
75 1768624 Spring Attachment Rod................................. 1
76 1768636 Extension Spring......................................... 1
78 1769872 Upper Brake Rod......................................... 1
79 1111609 Screw, 5/16-18x2-3/4................................... 2
80 1769874 Shift Rod................................................... 1
81 1769875 Ciutch Arm Pivot......................................... 1
83 1768630001 Shift Rod Bracket................................................ 1
84 1186308 Range Lock Screw. 1/4-20 x 1/2..................... 2
85 1769852023 Backplate.......................................................... 1
87 1770334 V-Belt....................................................... 1
90 1768194 Th read Form ing Screw, 3/8-16 x 1 -1 /2.. 1
91 1762042 Thread Forming Screw, 3/8-16 x 1................... 3
102 1186229 Hex Nut, 1/4-20.......................................... 1
159 1769038 Eye Bolt..................................................... 2
167 1769882 Pivot Shaft Assembly.................................... 1
169 1100350 Cotter Pin................................................... 3
168 1769878 Brake Arm.................................................. 1
170 1187961 Drive Pin. 5/32x1........................................ 1
171 1730851 Clevis Pin, 1/2 X1-1/4.................................. 1
172 1724491 Screw. 5/16-18x3/4...................................... 2
177 1740496 Flange Screw, 5/16-18x3/4............................ 2
302 1915936 Frame Weld ment /tss'y
(lncl.Ref.7).......................................... 1
303 1768180 Wheel Rim.................................................. 2
304 1756444 Tire........................................................... 2
305 1718086 Valve Stem................................................. 2
400 97092 Loctite 242, 0.02 oz. Tube.......................... N/l
403 1768818 Washer-flat................................................ 1
— 1905122 Owner’s Manual........................................... 1
