Craftsman 247.79452 - Manual (Page 24)

Craftsman 9 H.P. Horizontal Shaft Engine Model No. 143.999003 for Craftsman Log Splitter Model 247.794520
Key
No.
Part No. Description Qty.
Key
No.
Part No. Description Qty.
178 29752 Nut & Lock Washer. 1/4-28 2 280 36799A Heat Shield 1
182 30088A Screw, 1/4-28 X 1” 2 281 33013 Starter Bubble Cover 1
184 33263 Carburetor To Intake Pipe Gasket 1 282 650760 Screw, 8-32 x 3/8" 1
185 34707 Intake Pipe 1 285 35985B Starter Cup 1
186 34667 Governor Link 1 287 29752 Nut & Lock Washer, 1/4-28 4
200 34677 Control Bracket (Incl. 19,203,204 1 290 30962 Fuel Line 1
&206)
292 26460 Fuel Line Clamp 2
203 31342 Compression Spring 1
298 650665 Screw, 1/4-15x3/4" 2
204 651029 Screw, Torx T-10, 5-40 x 7/16" 1
300 34186A Fuel Tank (Incl. 292 & 301) 1
206 610973 Terminal 1
301 36246 Fuel Cap 1
207 33878 Throttle Link 1
305 35554 Oil Fill Tube 1
209 650821 Screw, 10-32 X 1/2" 2
307 35499 "0“ Ring 1
215 35882 Control Knob 1
308 35540 Fill Tube Clip 1
223 650378 Screw, Torx T-30, 5/16-18 x 1-1/8' 2
310 36205 Dipstick 1
224 27915A Intake Pipe Gasket 1
325 29443 Wire Clip 1
238 28820 Screw, 10-32 X 1/2" 2
327 35392 Starter Plug 1
239 27272A Air Cleaner Gasket 1
339 35880 Spacer 2
240 37104 Air Cleaner Body 1
340 34259 Fuel Tank Bracket 1
242 33267 Air Cleaner Bracket 1
341 34258A Fuel Tank Bracket 1
245 33268 Air Cleaner Filter 1
342 650273 Screw, 5/16-18x5/8" 2
245A 35881 Air Cleaner Filter 1
370G 35274 Oil Instruction Decal 1
250 33269A Air Cleaner Cover 1
370J 35703 Throttle Decal 1
251 650513 Wing Nut, 1/4-20 1
380 640112 Carburetor (Incl. 184) 1
260 36250 Blower Housing 1
390 590746 Rewind Starter 1
261 650788 Screw, 5/16-18x3/4“ 2
{NOTE: This engine cound have been
262 29747B Screw, Torx T-40, 5/16-24 x 21/ 2 built with 590704 starter.)
32“
400 36454 Gasket Set (Incl. Items Marked 1
264A 30063 Screw, Torx T-30, 1/4-20 x 1/2" 1 PKin Notes)
265 33272B Cylinder Head Cover 1 Incl. part #'S 27272A (1 ),27896A (2), 27915A
275 34185B Muffler 1
(1), 29673(1), 33263(1),
33629 (1), 34698A (1), 35262 (1), 36448 (1)
276 31588 Locking Plate 1
416 34479A Spark Arrestor Kit (Optional) 1
277 650729 Screw, 5/16-18 X 3-3/16" 1
900 0 Rep. Short Block 756321, order0
277A 651036 Screw. 5/16-18 X 3-31/32" 1
from 71 -999
278 36908 Spacer 1
900 0 Replacement Engine None 0
