Chapter 5: Local Management
5-38 6H128-08 and 6H129-08 User’s Guide
The following explains each Module Menu screen field as shown in
Figure 5-16 :
MODULE CONFIGURATION
The Module Configuration screen provides access to the Local
Management screens that are used to configure the 6H12X-08, and also to
the Module Specific Configuration screen. The Module Specific
Configuration screen provides access to the screens that allow the user to
check 6H12X-08 resources and set operating parameters specific to each
port. For details about the Module Configuration Menu screen, refer to
Section 5.14 . For details about the Module Specific Configuration screen,
refer to Section 5.21 .
MODULE STATISTICS
The Module Statistics screen provides statistics and performance
information for the 6H12X-08. For details about this screen, refer to
Section 5.25 .
NETWORK TOOLS
The Network Tools function resides on the 6H12X-08 and consists of a
series of commands that allow the user to access and manage network
devices.
Section 5.29 explains how to use the Network Tools utility.
5.14 MODULE CONFIGURATION MENU SCREEN
The Module Configuration Menu screen, Figure 5-17 , provides access to
the Local Management screens that allow you to configure and monitor
operating parameters, modify SNMP community names, set SNMP traps,
configure switch parameters and configure the 6H12X-08 ports.
NOTE
The following menu items on the Module Configuration Menu
screen may not display if the operational mode of the module
has been set to SECURE FAST VLAN:
SWITCH CONFIGURATION
SMARTTRUNK CONFIGURATION
Refer to your Release Notes to see if the functionality provided
by the above screens is supported in SECURE FAST VLAN
mode.
Section 5.15.9 provides instructions on setting the operational
mode.
