PARTS
CRAFTSMAN 3000 PSI Pressure Washer 580.753000
Main Unit —^ Exploded View and Parts List
Item Part#
Description
Item Part#
Description
1
M190156GS BASE
12
192796GS
KIT, Chem Hose & Filter
2
M187802GS HANDLE
13
192199GS
ASSY, Extension
3
187606GS
BILLBOARD
14
B1862BGS
GUN
4
192648GS
ASSY, Complete Hose Reel Kit
15
B5167GS
HOSE
6
194004GS
KIT, Inlet, Hose, Grdn, Srv
16
194298GS
THERMAL RELIEF
6
192134GS
KIT, Engine Mounting Hardware
17
190668GS
KIT, Handle Fasteners
7
95457GS
ADAPTER, Hose
18
192553GS
KIT, Vibration Mount
8
192131GS
KIT, Pump Mounting Hardware
19
192526GS
KIT, Wheel
9
194236CGS NOZZLE, Turbo
20
23139DGS
KEY
10
194062GS
PUSHNUT
21
194003GS
ASSY, Pump (see page 21)
11
B5646GS
KIT, Spray Tips
900 NSP
ENGINE
Items NotJllustr^ted:
:
;;;;;;;;;; Part:#: ^ 111111111 Description:
194i;9QGS ; ; ; ;
s
^
anual
, owner's
......................
AB3C61BGS OIL;
Décais
Botile
Gptlonat Accessories Not Htustrated
71751S7GS
/1T5i:97GS
7175199GS
/17511SGS
/175116GS
7174400GS
Garden Hose; Quick Connect
Accessory Quick Connect
Rotating Brush Kit
; ;2S‘; Replacernent Hose ;;;;;;;;;;
O Ring Repair Kit
Turbo Nozzle ; ; ; ; ; ;
74401GS........ 25‘ Extension Hose
Optional Accessories Not Ittustrated
.......... ............................ Hose Reel................................
; T T T T174403GS T T TPurnp Caver T T T T T T ; T
::::::::: : T174300GS : : T T HOUSÒ WaSh ConCentrafe: : : : : : :
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;; ;(makes4 :gailons)...................
7174301GS
Deck Wash Concen'rate
(makes 2 gallons)
n /4302GS
VehicloiSoat Wash
Concentrate (makes 4 gallons)
7174303GS
Degreaser Concentrate
(makes 4 gallons)
/174307GS
Mold/Mildew Concentrate
(makes 2 gallons)
